Suzhou Blauberg Motoren Technology Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov muag khoom ntawm blauberg bc-f120b-ec-00 120mm ec rau pem hauv ntej nkhaus centrifugal ntxuam hauv Suav teb. Txais tos mus yuav cov khoom lag luam wholesale zoo tshaj plaws hauv Suav teb ntawm no thiab tau txais cov lus hais los ntawm peb lub hoobkas. Rau nqe kev sab laj, tiv tauj peb.
Cov ntaub ntawv yooj yim
| Qauv | BC-F120B-EC-00 | Yam khoom | EC Forward Curved Centrifugal Ntxuam |
| Theem | 1~ | Rated Voltage | 115 VAC |
| Ntau zaus | 50/60 Hz | Nominal Ceev | 3230 rpm ib |
| Max. Lub zog nkag | 90 W | Max. Input Tam sim no | 1.34 A |
| Suab Level | 67 dB (A) | Ambient Kub | -25 ° C rau +60 ° C |
| Daim ntawv pov thawj | CCC, CE, RoHS | Hnub tso tawm | Saib cov khoom specification |
Kev piav qhia
| Qhov ntev | 120 x 120 x 84 mm | Lub cev muaj zog | 72mm ib |
| Cov khoom siv impeller | Hlau | Number of Blades | Saib cov khoom specification |
| Cua Flow Direction | Tag nrho ib ncig | Kev sib hloov | Clockwise, saib rau rotor |
| Rotor Nto | Xiav yas txau | Qhov hnyav | Saib cov khoom specification |
| Qib Kev Tiv Thaiv | IP55 | Rwb thaiv tsev Class | Chav B |
| Kev ua haujlwm hom | S1 | Cov kabmob | Pob bearing |
| Installation Txoj hauj lwm | Ib qho | Cooling Holes / Txiav- tawm | Rotor sab |
| Kev khiav dej num | 5% -90% RH | Cia Humidity | 5% -95% RH |
| Cia Kub | -40 rau +80 deg C | Cable Ntev | 500+/-20 hli |
| Technical nta | 10 VDC tso zis; 0-10 VDC/PWM ceev tswj; xauv -rotor, thermal, overvoltage, undervoltage, overcurrent thiab soft-start tiv thaiv | ||
| Dielectric zog | 1800 VAC / 50 Hz, 1 s; leakage tam sim no<=10 mA | ||
Khoom siv
| 1 | Kev them nqi | 9 | Cov khoom siv cua txias Project |
| 2 | Kitchen Smoke Exhaust System | 10 | Qhov project chav tsev |
| 3 | FFU Project | 11 | UAS Project |
| 4 | Khoos phis tawj chav txias | 12 | Cua Purifier Project |
| 5 | Rail Transit Air-Kub txias | 13 | Heat Exchanger Project |
| 6 | Cov Khoom Siv Hluav Taws Xob | 14 | Telecom Container Project |
| 7 | FanGrid Project | 15 | Data Center Txias Project |
| 8 | Cov khoom siv cua tshuab ua pa | 16 | Industrial Cooling System |
Huab cua Performance
Zuag qhia tag nrho Dimensions
Kev sib txuas hluav taws xob
Txuas lub zog thiab tswj cov kab nruj nruj raws li daim duab kos. Xa mus rau cov khoom specification kom tiav kev nyab xeeb, cia, txij nkawm thiab warranty ntaub ntawv.
Download tau
Download BC-F120B-EC-00 Product Specification
